INTRODUCTION
Stranded Air Blown Micro Cables are ultra lightweight with and small diameter and designed for metro feeder or access network to be blown into a micro duct by air-blown installation. As the cable allows the deployment of currently required fiber count, the micro cable provides a lower initial investment and the flexibility to install and upgrade to the latest fiber technologies after the initial installation.
KEY FEATURES
Perfect cable structure with high fiber density
Accurate fiber length balance to ensure stable performance
No gel in cable core for water blocking
Sheath structure innovation to enhance blowing performance
Greater blowing distance
Fiber: G.G652D, G.657A1, G.657A2
SPECIFICATION
|
P/N |
Fiber
count |
Nominal
diameter |
Nominal
weight |
Max
tensile strength |
Temperature |
|
MICROL-12G652D-PE |
12 |
5.2±0.1 |
25 |
500 |
-40 to +70 |
|
MICROL-24G652D-PE |
24 |
5.2±0.1 |
25 |
500 |
|
|
MICROL-36G652D-PE |
36 |
5.2±0.1 |
25 |
500 |
|
|
MICROL-48G652D-PE |
48 |
5.2±0.1 |
25 |
500 |
|
|
MICROL-60G652D-PE |
60 |
5.2±0.1 |
25 |
500 |
|
|
MICROL-72G652D-PE |
72 |
5.2±0.1 |
25 |
500 |
|
|
MICROL-96G652D-PE |
96 |
6.1±0.1 |
35 |
1000 |
|
|
MICROL-144G652D-PE |
144 |
7.9±0.1 |
57 |
1200 |
|
|
MICROL-192G652D-PE |
192 |
7.9±0.1 |
55 |
500 |
-20 to +70 |
|
MICROL-216G652D-PE |
216 |
7.9±0.1 |
55 |
500 |
|
|
MICROL-288G652D-PE |
288 |
9.4±0.1 |
78 |
1000 |
BLOWING PERFORMANCE
|
Fiber
count |
Blowing machine |
Suitable
microduct |
Blowing
distance |
Blowing
distance |
Blowing
distance |
|
12 to 72 |
PLUMETTAZ
PR-140 |
10/8 or 12/10 |
1800 |
2300 |
/ |
|
96 |
10/8 or 12/10 |
1800 |
2300 |
/ |
|
|
144 |
12/10 |
/ |
1200 |
/ |
|
|
192 to 216 |
12/10 |
/ |
1500 |
/ |
|
|
288 |
14/12 |
/ |
/ |
1500 |
ABOUT P/N: MICROL-2G652D-PE
MICROL: cable type | 2: fiber count | G652D: G652D, G657A1, G657A2 & multimode fiber available | PE: sheath material
